Schneider Electric GV2L14 TeSys GV2 Motor Circuit Breaker 3P 10 A Magnetic | MPCB
Schneider Electric GV2L14 TeSys GV2 Motor Circuit Breaker 3P 10 A Magnetic | MPCB
Couldn't load pickup availability
The Schneider Electric GV2L14 is a TeSys GV2 magnetic-only motor circuit breaker with a setting range of 10 A. It provides magnetic short-circuit protection and isolation and is typically combined with a TeSys contactor and thermal overload relay.
Key features
- Magnetic trip for fast short-circuit protection
- Ideal for motor-starter combinations with separate overload relays
- Clear ON/OFF/TRIP indication and lockable handle for safe maintenance
- Direct mounting with TeSys contactors to build compact starters
- Accepts auxiliary contacts, fault signalling contacts and undervoltage releases
- DIN-rail or panel mounting
Technical specifications
| Brand | Schneider Electric |
|---|---|
| Part number (SKU) | GV2L14 |
| Product range | TeSys GV2 |
| Device type | Motor circuit breaker / manual motor starter (MPCB) |
| Protection | magnetic-only (short-circuit only – use with a thermal overload relay) |
| Setting / rated current | 10 A |
| Poles | 3P |
| Control | Rotary handle |
| Mounting | 35 mm DIN rail or panel |
| Standard | IEC/EN 60947-2, IEC/EN 60947-4-1 |
Typical applications
- Water pumps, booster sets and fire pumps
- Fans, blowers, compressors and conveyors
- HVAC, chiller and cooling-tower motors
- Machine control panels and MCCs
- Direct-on-line motor starters
Selection guide
Select the range so that the motor full-load current (from the nameplate) falls inside the setting range, then set the dial exactly to the nameplate current. For example, a 7.5 kW 400 V motor draws about 15 A, so a 13–18 A range is appropriate.
Frequently asked questions
What motor size suits the GV2L14?
With a 10 A setting range it suits three-phase motors whose full-load current lies within that range.
Do I need an overload relay with this breaker?
No for thermal-magnetic GV2ME/GV2P/GV3P/GZ1E types, which include overload protection. Yes for magnetic-only GV2L types, which must be combined with a thermal overload relay.
Buy Schneider GV2L14 in Egypt
Spark Egypt supplies the original Schneider Electric GV2L14 motor circuit breaker (MPCB) with a VAT tax invoice for electrical contractors, panel builders, factories, consultants and facility-maintenance teams. Delivery is available to Cairo, Giza, New Cairo, 6th of October, Sheikh Zayed, the New Administrative Capital, Alexandria, the Delta, the Canal cities and Upper Egypt. Our technical team can confirm ratings, compatible accessories and equivalent references before you order, and project quantities are quoted on request.
