Schneider Electric TeSys D LC1D Contactors | LC1D115M7 & LC1D150M7, 3-Pole, 115A-150A AC-3, 220V AC Coil Options

LC1D115M7 / LC1D150M7 is part of the Schneider Electric TeSys D LC1D range of 3-pole AC-3 motor contactors for dependable switching and control of three-phase motors. The LC1D frame is rated 115A-150A for AC-3 motor duty, with the LC1D115M7 / LC1D150M7 220V AC coil option for common Egyptian control-panel supplies.

TECHNICAL SPECIFICATIONS
Brand: Schneider Electric
Series: TeSys D / LC1D
Reference: LC1D115M7 / LC1D150M7; frame: LC1D
Utilization category: AC-3 motor control
Rated operational voltage: up to 440V AC for AC-3 duty
Rated current: 115A-150A
Motor reference: up to 55-75kW at 400V, subject to duty and installation conditions
Main contacts: 3 poles, 3 normally-open power contacts

VARIANT GUIDE
Part number / SKU | Coil voltage | Current | Main contacts | Typical motor duty
LC1D115M7 | 115A, 220V AC | 115A-150A | 3P, 3 NO | AC-3 up to 55-75kW at 400V
LC1D150M7 | 150A, 220V AC | 115A-150A | 3P, 3 NO | AC-3 up to 55-75kW at 400V

Choose LC1D115M7 / LC1D150M7 when your control circuit uses 220-240V AC. Other LC1D coil variants are available for 24V AC, 48V AC, 110V AC, 380V AC or 24V DC control systems. Confirm coil voltage, motor current, short-circuit protection and overload relay coordination before installation.

Buy genuine Schneider Electric TeSys D LC1D contactors from Spark for electrical panels, industrial motor starters, pump and HVAC control, and electrical spare-parts requirements across Egypt.
