LC1K1610B7 | موصل TeSys K - 3P - تيار متردد-3 <= 440 فولت 16 أمبير - 1 لا مساعد. - ملف 24 فولت تيار متردد
LC1K1610B7 | موصل TeSys K - 3P - تيار متردد-3 <= 440 فولت 16 أمبير - 1 لا مساعد. - ملف 24 فولت تيار متردد
The Schneider Electric LC1K1610B7 is the largest model in the TeSys K range — a compact 3-pole AC contactor rated 16A (AC-3) / 35A (AC-1) for motors up to 7.5 kW at 400V. The 24V AC coil enables direct PLC output control. Integrated 1 NO auxiliary contact. Same ultra-compact 45mm footprint as smaller TeSys K models — maximising DIN-rail density in control panels.
Technical Specifications
| Part Number (MPN) | LC1K1610B7 |
|---|---|
| Rated Current (AC-3) | 16 A |
| Rated Current (AC-1) | 35 A |
| Motor Power at 400V | 7.5 kW / 10 HP |
| Coil Voltage | 24V AC 50/60 Hz |
| Auxiliary Contacts | 1 NO (integrated) |
| Poles | 3 (3NO) |
| Width | 45 mm |
| Mounting | 35mm DIN rail or panel mount |
| Operating Temperature | -25°C to +50°C |
| Standard | IEC/EN 60947-4-1, UL, CSA, CCC |
| Series | Schneider Electric TeSys K |
| Brand | Schneider Electric |
Applications
Top-of-range TeSys K for DOL starting of 7.5 kW motors in water pumps, air handling units, industrial compressors, and conveyor drives. The 24V AC coil allows seamless integration with 24V PLC systems for fully automated motor control.
Is the LC1K1610B7 the largest TeSys K contactor? Yes — the TeSys K range covers 6A to 16A (AC-3). For larger motors above 7.5 kW, step up to the Schneider Electric TeSys D range (LC1D series).
