LC1K1201B7 | موصل TeSys K - 3P - تيار متردد-3 <= 440 فولت 12 أمبير - ملف مساعد 1 NC - 24 فولت تيار متردد
LC1K1201B7 | موصل TeSys K - 3P - تيار متردد-3 <= 440 فولت 12 أمبير - ملف مساعد 1 NC - 24 فولت تيار متردد
The Schneider Electric LC1K1201B7 is a TeSys K compact 3-pole AC contactor rated 12A (AC-3) / 25A (AC-1) for motors up to 5.5 kW at 400V. The 24V AC coil allows direct connection to PLC output modules. Integrated 1 NC auxiliary contact for interlock applications. Multi-standard certified (IEC, UL, CSA, CCC).
Technical Specifications
| Part Number (MPN) | LC1K1201B7 |
|---|---|
| Rated Current (AC-3) | 12 A |
| Rated Current (AC-1) | 25 A |
| Motor Power at 400V | 5.5 kW / 7.5 HP |
| Coil Voltage | 24V AC 50/60 Hz |
| Auxiliary Contacts | 1 NC (integrated) |
| Poles | 3 (3NO) |
| Width | 45 mm |
| Mounting | 35mm DIN rail or panel mount |
| Operating Temperature | -25°C to +50°C |
| Standard | IEC/EN 60947-4-1, UL, CSA, CCC |
| Series | Schneider Electric TeSys K |
| Brand | Schneider Electric |
Applications
DOL and reversing starters for 5.5 kW three-phase motors in pump systems, ventilation, conveyor drives, and compressors. The 1 NC contact is widely used for forward/reverse interlocking in reversing motor starters, preventing simultaneous energisation.
What is the difference between LC1K1201B7 and LC1K1210B7? Both are 12A / 5.5 kW with 24V AC coil — the 1201 has a 1 NC auxiliary contact; the 1210 has a 1 NO auxiliary contact.
