LC1K0601B7 | موصل TeSys K - 3P - تيار متردد-3 <= 440 فولت 6 أمبير - 1 مساعدة NC - ملف تيار متردد 24 فولت
LC1K0601B7 | موصل TeSys K - 3P - تيار متردد-3 <= 440 فولت 6 أمبير - 1 مساعدة NC - ملف تيار متردد 24 فولت
The Schneider Electric LC1K0601B7 is a TeSys K ultra-compact 3-pole AC contactor rated 6A (AC-3) / 14A (AC-1) for motors up to 2.2 kW at 400V. The 24V AC coil connects directly to PLC output cards and low-voltage control circuits. Includes an integrated 1 NC auxiliary contact — ideal for interlock circuits and safety applications. One of the smallest contactors available in the market at only 45mm wide.
Technical Specifications
| Part Number (MPN) | LC1K0601B7 |
|---|---|
| Rated Current (AC-3) | 6 A |
| Rated Current (AC-1) | 14 A |
| Motor Power at 400V | 2.2 kW / 3 HP |
| Coil Voltage | 24V AC 50/60 Hz |
| Auxiliary Contacts | 1 NC (integrated) |
| Poles | 3 (3NO) |
| Width | 45 mm |
| Mounting | 35mm DIN rail or panel mount |
| Operating Temperature | -25°C to +50°C |
| Standard | IEC/EN 60947-4-1, UL, CSA, CCC |
| Series | Schneider Electric TeSys K |
| Brand | Schneider Electric |
Applications
Direct-on-line (DOL) motor starters, PLC-controlled switching circuits, reversing starters, conveyor drives, pump control, and HVAC fan control. The 1 NC auxiliary contact is used for safety interlocking, run-status indication, and holding-circuit wiring.
What is the difference between LC1K0601B7 and LC1K0610B7? The LC1K0601B7 has a 1 NC integrated auxiliary contact; the LC1K0610B7 has a 1 NO auxiliary contact — same 6A / 2.2 kW rating and 24V AC coil.
